Description
whisper-quiet compressor JUN-AIR 4-25 motor oil lubricated with pressure reducer JUNAIR”.
from 2007
The oil-lubricated JUN-AIR compressors are always the optimal solution,
when a noiseless compressed air supply is required.
At 45 dB(A), the volume is well below the sound level of a normal conversation.
Silent, vibration-free operation and the compact design allow installation directly at the workplace.
Technical data:
max. Pressure 18 bar
Suction capacity 50 l/min
Effective delivery rate: 32 l/min at 8 bar
Volume 45 dB(A)
Duty cycle / pause 15 min. / 15 min.
Compressor number 1
Cylinder per compressor 1
Pressure vessel volume 25 l
Permissible ambient temperature +1°C to +40°C
Supply voltage 230 V, 50 Hz
Motor power 0.34 kW
Current consumption 2.9 A
Thermal protection Integrated
Weight 29 kg
Dimensions (LxWxH) 378 x 378 x 555
